ob_ellipse class — ob_ellipse • ggdiagram

Makes ellipses and superellipses

Usage

ob_ellipse(
  center = ob_point(0, 0),
  a = 1,
  b = a,
  angle = 0,
  m1 = numeric(0),
  m2 = numeric(0),
  label = character(0),
  alpha = numeric(0),
  color = character(0),
  fill = character(0),
  linewidth = numeric(0),
  linetype = numeric(0),
  n = numeric(0),
  style = S7::class_missing,
  x = numeric(0),
  y = numeric(0),
  id = character(0),
  ...
)

Arguments

center: point at center of ellipse. Settable.
a: distance of semi-major axis. Settable.
b: distance of semi-minor axis. Settable.
angle: ellipse rotation. Settable.
m1: exponent of semi-major axis. Settable. Controls roundedness of superellipse
m2: exponent of semi-minor axis. Settable. By default equal to m1. If different, some functions may not work as expected (e.g., point_at).
label: A character, angle, or label object
alpha: numeric value for alpha transparency
color: character string for color
fill: character string for fill color
linewidth: Width of lines
linetype: type of lines
n: number of points in ellipse (default = 360). Settable.
style: gets and sets style parameters
x: x-coordinate of center point. If specified, overrides x-coordinate of @center.
y: x-coordinate of center point. If specified, overrides y-coordinate of @center.
id: character string to identify object
...: <dynamic-dots> properties passed to style object

Value

ob_ellipse object

Additional properties

@aesthetics: A list of information about the object's aesthetic properties
@angle_at: A function that finds the angle of the specified point in relation to the ellipse's center
@area: area of the ellipse
@bounding_box: a rectangle that contains all the ellipses
@focus_1: left focus point of the ellipse
@focus_2: right focus point of the ellipse
@geom: A function that converts the object to a geom. Any additional parameters are passed to ggforce::geom_ellipse.
@length: Gets the number of ellipses
@normal_at: A function that finds a point perpendicular to the ellipse at angle theta at the specified distance. The definitional parameter is passed to the point_at function. If a point is supplied instead of an angle, the point is projected onto the ellipse and then the normal is calculated found from the projected point.
@perimeter: returns the ellipse's perimeter
@point_at: A function that finds a point on the ellipse at an angle theta. If definitional is FALSE (default), then theta is interpreted as an angle. If TRUE, then theta is the parameter in the definition of the ellipse in polar coordinates.
@polar_line_at: A function that creates an ob_line that passes through the ellipse's center and the point specified in x.
@polygon: a tibble containing information to create all the polygon points in ellipse.
@tangent_at: A function that finds a tangent line on the ellipse. Uses point_at to find the tangent point at angle theta and then returns the tangent line at that point. If a point is supplied instead of an angle, the point is projected onto the ellipse and then the tangent line is found from there.
@tibble: Gets a tibble (data.frame) containing parameters and styles used by ggforce::geom_ellipse.

Examples

# specify center point and semi-major axes
e <- ob_ellipse(center = ob_point(0,0), a = 2, b = 3)
ggdiagram() +
  e
