ob_rectangle class

Usage

ob_rectangle(
  center = S7::class_missing,
  width = numeric(0),
  height = numeric(0),
  east = S7::class_missing,
  north = S7::class_missing,
  west = S7::class_missing,
  south = S7::class_missing,
  northeast = S7::class_missing,
  northwest = S7::class_missing,
  southwest = S7::class_missing,
  southeast = S7::class_missing,
  angle = numeric(0),
  vertex_radius = numeric(0),
  label = character(0),
  alpha = numeric(0),
  color = character(0),
  fill = character(0),
  linewidth = numeric(0),
  linetype = numeric(0),
  style = S7::class_missing,
  x = numeric(0),
  y = numeric(0),
  id = character(0),
  ...
)

Arguments

center: ob_point at center of the rectangle
width: width
height: height
east: right middle point (ob_point)
north: top middle point (ob_point)
west: left middle point (ob_point)
south: top middle point (ob_point)
northeast: upper right point (ob_point)
northwest: upper left point (ob_point)
southwest: lower left point (ob_point)
southeast: lower right point (ob_point)
angle: Rectangle rotation. Settable.
vertex_radius: A numeric or unit vector of length one, specifying the corner radius for rounded corners
label: A character, angle, or ob_label object
alpha: numeric value for alpha transparency
color: character string for color
fill: character string for fill color
linewidth: Width of lines
linetype: type of lines
style: a style object
x: overrides x-coordinate in center@x
y: overrides y-coordinate in center@x
id: character string to identify object
...: <dynamic-dots> properties passed to style

Value

ob_rectangle object

Additional properties

@xy: returns a matrix of xy coordinates of center points
@aesthetics: A list of information about the object's aesthetic properties
@area: returns rectangle area
@bounding_box: returns the ob_rectangle that contains all the rectangles in the object
@perimeter: returns the rectangle perimeter
@side: returns the east, north, west, and south ob_segment of the rectangles
@length: returns the number of rectangles in the object
@geom: a function that returns a ggforce::geom_shape object
@normal_at: A function that finds a point perpendicular to the rectangle at angle theta at the specified distance.
@point_at: A function that finds a point on the rectangle at an angle theta
@tangent_at: A function that finds a tangent line on the rectangle. Uses point_at to find the tangent point at angle theta and then returns the tangent line at that point. If a point is supplied instead of an angle, the point is projected onto the ellipse and then the tangent line is found from there.
@tibble: Gets a tibble (data.frame) containing parameters and styles used by ggforce::geom_shape

Examples

ggdiagram() +
  ob_rectangle(center = ob_point(0,0), width = 3, height = 2)
